The 3.5 Bore x 24 Stroke Hydraulic Cylinder from Chief, manufactured by Bailey, is engineered for exceptional performance in demanding hydraulic applications. This heavy-duty cylinder is designed for durability and reliability, making it an ideal choice for both industrial and agricultural use.

• Bore Diameter: 3.5 inches
• Stroke Length: 24 inches
• Extended Length: 58.25 inches
• Retracted Length: 34.25 inches
• Rod Diameter: 1.5 inches
• Port Size: SAE 8 ports
• Column Load Capacity: 23,875 lbs
• Material: Heavy-duty steel construction
• Warranty: 2-year warranty for peace of mind

This hydraulic cylinder showcases a robust design, ensuring seamless operation even under high-pressure conditions. The honed cylinder bore and hard chrome-plated rod contribute to its superior performance and longevity.

NOTE! Ensure proper measurements and type of application to prevent bent rods. Misuse cases are not covered under warranty.

Same-Day Shipping: All orders placed by 3 PM will be shipped on the same day (excluding weekends and holidays).

Tariff- cylinders.

Manufactured in Europe.

If you have questions regarding choosing the correct hydraulic cylinder for your needs, don’t hesitate to reach out to us at (800) 823-4937.
