Home » Hydraulics Shop » Hydraulic Cylinders » Double Acting Hydraulic Cylinders » 3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister

Free Shipping

3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister - Image 2

3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister - Image 3

3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister - Image 4

This 3.5" bore x 28" stroke hydraulic cylinder offers heavy-duty performance with a 3500 PSI rating and a 23,000 LB column load. Order now with free shipping!

Specifications

Weight	55.0 lbs
Dimensions	40 × 5 × 5 in
Cylinder Bore	3.5"
Cylinder Stroke Ranges	28
Cylinder Extended Length	66
Cylinder Style	Welded
Cylinder Retracted Length	38
Cylinder Port Size	ORB – 8
Manufacturer	MagisterHyd
Cylinder Outer Diameter	3.86 in
Cylinder Rod Diameter	1.75 in
Cylinder Overall Length	40 in
Cylinder PSI	3500 PSI
Cylinder Column Load	23,000 lbs
Cylinder Oil Volume	4.66 qts
Cylinder Rod Type	Chrome Plated
Cylinder Rod End	Cross Tube
Cylinder Action	Double Acting

Overview

Bore Diameter: 3.5 inches
Stroke Length: 28 inches
Overall Length: 40 inches
Retracted Length: 38 inches
Extended Length: 66 inches
Pressure Rating: 3500 PSI
Column Load: 23,000 LBs
Oil Volume: 4.66 QTs
Rod Type: Chrome Plated
Action: Double Acting
Port Size: SAE 8
Weight: 55 LBs
Style: Welded
Rod End: Cross Tube

Designed for heavy-duty applications, this 3.5 x 28 hydraulic cylinder by Northern Hydraulics is the perfect partner for your hydraulic system, delivering reliable performance and exceptional durability. With a robust pressure rating of 3500 PSI and a column load capacity of 23,000 LBs, it is ideal for a variety of tasks.

The cylinder features double-acting action, ensuring efficient operation in both extension and retraction. Constructed with a chrome-plated rod for enhanced strength, this hydraulic cylinder is built to withstand the toughest conditions.

Key features of the WCTN3.5×28 include:

Heavy-duty design for industrial applications
High-pressure capability for efficient lifting and pulling
Easy installation with standard port sizes
Durable welded construction for extended service life

Enjoy free ground shipping on all orders and the peace of mind that comes with purchasing from a trusted provider. For questions or assistance with your hydraulic cylinder needs, please reach out to us at (800) 823-4937.

Trusted Manufacturing Partnership

This hydraulic cylinder is proudly manufactured by our longtime partner, Magister Hydraulics, known for their exceptional craftsmanship and reliability. At Northern Hydraulics, we're honored to offer their proven designs under our own brand, ensuring you get the best of both worlds — OEM-grade performance backed by our dedicated support and service.

SKU: WCTN3.5x28

4.6

9 reviews

3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister

Name: 3.5 inch bore x 28 inch stroke hydraulic cylinder | Magister
Brand: MagisterHyd
SKU: WCTN3-5x28
Price: 402 USD
Availability: InStock
Rating: 4.56 (9 reviews)

$402.00

In stock

No sales tax

Free shipping

Expected delivery Jun 05 - Jun 09

1+ $ 402.00/piece

4+ $ 381.90/piece -5%

8+ $ 361.80/piece -10%

Looking for help or a discount?

Call (800) 823-4937

Reviews (9)

Rating & Reviews ( 9 4.6

dan k.

Rated 4 out of 5

2 months ago

Thing's a tank, really happy with how it performs under heavy use — took a little longer than expected to arrive but once it got here everything checked out and install was straightforward.
BJ's Repair

Rated 5 out of 5

4 months ago

Ordered this for a customer's skid steer attachment. Seals were tight, finish was clean, and it went together without any headaches. Customer's been running it hard for a few weeks with zero problems. Definitly ordering from here again.
Terry M.

Rated 3 out of 5

5 months ago

Cylinder works fine under load but the paint had a couple chips out of the box, which was a little annoying for the price. Seals seem solid and it's been holding pressure fine, so I can't complain too much about the actual function. Would've liked better packaging.
Northland Excavating

Rated 5 out of 5

5 months ago

Dropped right into our application, no modifications needed. Welds look clean and it's handling the work without any issues whatsoever.
Jake R.

Rated 5 out of 5

6 months ago

works great

4.6/5

Rated 4.56 out of 5

9 reviews

5 star

4 star

3 star

2 star

1 star
