Home » Hydraulics Shop » Hydraulic Valves » Selector Valve » DSV-62-10-24-DIN Selector Valve – Versatile and Efficient Hydraulic Control

Explore the DSV-62-10-24-DIN Selector Valve, a versatile 12-volt DC valve for hydraulic systems. Capable of switching between circuits with ease. Shop now!

Specifications

Weight	11.5 lbs
Dimensions	4 × 4 × 4 in
Manufacturer	Dynamic Fluid Components
Valves Max Flow Rate	24.0 gpm
Valves Operating Pressure	3600 psi
Valves Oil Temperature Range	-4°F – 158°F
Valves Viscosity Range	70-1790 SSu
Valves Filtration Req	NAS 1638 8
Valves Supply Voltage	24VDC
Valves Amperage Rating	1.21A for DC 24V
Valves Max Ambient Temp	125° F
Valves Max Coil Temp	356° F
Valves Duty Cycle	Continuous
Valves Port	7/8-14 – SAE-10

Overview

The DSV-62-10-24-DIN Selector Valve by Dynamic Fluid Components is a versatile hydraulic control valve designed for efficient circuit switching.

Features:

Operated by a continuously rated wet pin solenoid
Capable of switching from one circuit to another at various flows and pressures
Connects to directional control valves to direct flow to and from two separate devices
Stackable up to 3 units for controlling more than two circuits
Minimizes the need for additional pipes and fittings
Can be connected to a pump to direct flow to different circuits

Part of the DSV series, this valve offers efficient hydraulic control and is perfect for applications requiring precise flow direction. Upgrade your hydraulic system with the DSV-62-10-24-DIN Selector Valve today!

SKU: DSV-62-10-24-DIN

DSV-62-10-24-DIN Selector Valve – Versatile and Efficient Hydraulic Control

Name: DSV-62-10-24-DIN Selector Valve - Versatile and Efficient Hydraulic Control
Brand: Northern Hydraulics Inc.
SKU: DSV-62-10-24-DIN
Price: 241.78 USD
Availability: InStock
