Discover the Dynamic Fluid Components JPLS-3000 hydraulic spool, designed for optimal performance in hydraulic systems. This model features a hydraulically-balanced, chrome-plated spool and pressure release detent that is adjustable from 1000 to 2000psi.

Key Features:

• Hydraulically-balanced spool
• Pressure release detent adjustable up to 2000psi
• Recommended for systems with flows up to 25 gpm
• Adjustable relief valve up to 2500 psi

When the tandem center spool is in the neutral position, hydraulic flow is diverted to the return line, allowing for minimal wear and tear on the pump. This hydraulic spool is suitable for applications where precision control and efficient operation are essential.

Technical Specifications:

• Max Operating Pressure: 2750 psi
• Max Tank Pressure: 150 psi
• Max Flow Rating: 25 gpm
• Relief Valve Setting: 2250 psi
• Recommended Filtration: ISO 4406 19/17/14
• Max Operating Temperature: 180°F
• Standard Port Size: 1/2” NPT
• Weight: 10 lbs

Enhance the performance of your hydraulic system with the Dynamic Fluid Components JPLS-3000 hydraulic spool. Order yours today!
