Technical Overview

The Parker 43 Series Fittings, specifically the 1B143-6-6 model, is an advanced hydraulic fitting designed for high-performance applications. This 90° female BSP parallel pipe swivel elbow fitting features a unique crimp style that allows for quick assembly with Parker’s range of Parkrimp crimpers.

With its no-skive hose attachment feature, the assembly process is simplified and eliminates the risk associated with premature hose failure due to improper skiving of the hose cover. The fitting is manufactured from durable steel and comes with Chromium-6 free plating, making it suitable for a wide array of hydraulic and industrial applications.

Specifications

• Part Number: 1B143-6-6
• Type: 90° Female BSP Parallel Pipe Swivel Elbow
• Connection Size: 5/8 Inch
• Material: Steel
• Plating: Chromium-6 Free
• Weight: 0.231 lbs

Features and Benefits

• Quick assembly with Parkrimp crimpers
• No need to remove outer cover of the hose for assembly
• Reduces risk of premature hose failure
• Robust steel construction for durability
• Ideal for use with Parker hydraulic braided, light spiral, specialty, suction, and return hoses
• Made in USA under strict quality standards

Applications

• Hydraulic systems in various industrial settings
• Agricultural machinery
• Construction equipment
• Fluid transfer systems

Quality and Certification

Parker 43 Series Fittings are manufactured to meet rigorous Parker quality standards and applicable industry certifications. The fittings undergo stringent testing processes ensuring reliability and long-term performance in demanding applications.
