Downtime drains $1,200 daily from operators relying on Vickers V10 pumps. The V101P3P11B20R delivers 3 GPM at 2500 PSI, proven in over 4,800 installations. Most users see payback in under 3 months.
Technical Specifications
Flow Performance
At 3 GPM, the V101P3P11B20R hits the efficiency sweet spot for light industrial and mobile hydraulic equipment. This matches a Vickers V10’s requirements exactly, eliminating guesswork. Operators report saving up to 4 hours weekly versus retrofitting alternatives.Performance stays consistent from startup to 4000 RPM maximum speed. After 2,000 hours, efficiency remains above 92%. Comparable gear pumps drop to 78% by that milestone.Installation takes just 35 minutes using standard shop tools. The 2-bolt SAE “A” flange fits dozens of machines without adapters. Compatibility with ISO 32-68 hydraulic oil prevents common seal failures.
Efficiency & Durability
Maintains consistent efficiency throughout operational lifespan.
Features and Benefits
- Direct Vickers Interchange: 100% model-code compatibility eliminates installation errors. Maintenance teams report 38% fewer fitment issues.
- Pressure Handling: 2500 PSI max rating prevents overload failures. Fleet operators see a 29% drop in unplanned shutdowns.
- Same-Day Shipping: Orders placed by 2 PM MST ship same day. Downtime costs drop by $350 per event.
Operational Information
Cold starts succeed down to 10°F. Continuous operation rated for 2,000 hours at 2500 PSI. Handles 10% overload spikes without damage. Replace when efficiency falls below 88%.
Quality Assurance
Manufactured to the highest standards with rigorous quality control throughout the production process.
For technical support and assistance, contact our hydraulics specialists at (800) 823-4937.
| Weight | 12.0 lbs |
|---|---|
| Pump Mounting Flange | 2-Bolt Flange (SAE "A" size) |
| Manufacturer | Fluidyne Fluid Power |
| Pumps Drive Shaft | 3/4" Straight Shaft with Key (1.75" extension) |
| Pumps Rotation | Right-Hand (Clockwise) |
| Pumps Max Pressure | 2500 psi |
| Pumps Rated Speed | 1200 RPM |
| Pumps Max Speed | 4000 RPM |
| Pumps Displacement | 9.8 cm³/r (0.60 in³/r) |
| Pumps Ports In | G1" BSPP Straight Thread |
| Pumps Ports Out | G1/2" BSPP Straight Thread |
Compatibility & Applications
Our extensive field experience—see case studies applications—shows the V101P3P11B20R excels as a drop-in Vickers replacement. For additional options, review our single stage vane pumps line.
Direct Replacement Information
The V101P3P11B20R from Fluidyne replaces Vickers V101P3P11B20R units in systems, part of our Vickers replacement pumps collection for seamless compatibility. requiring a 9.8 cm³/r (0.60 in³/r) displacement and up to 2500 PSI maximum pressure. This direct Vickers replacement is 100% interchangeable, meeting SAE J744 mounting standards and supporting rated speeds up to 1200 RPM. See our full line of vane pumps for additional technical options..
- Mounting Pattern: SAE ‘A’ 2-bolt
- Inlet Port: G1″ BSPP
- Outlet Port: G1/2″ BSPP
Common Applications
Commonly used in agricultural equipment, construction machinery, utility vehicles, and other applications detailed in our application guides.
- agricultural equipment
- construction machinery
- utility vehicles
Important: Verify pump model V101P3P11B20R matches your existing Vickers unit before ordering. For broader product compatibility, visit our hydraulic pumps overview. For technical assistance, contact (800) 823-4937.
Purchasing Information
All single stage vane pumps are in-stock for rapid fulfillment—see our V101B3B0C20R024 model for similar flow and performance.
Availability & Delivery
Most hydraulic pumps ship within 1-2 business days. Made-to-order items typically require 5-7 business days.
For current availability on V101P3P11B20R, call (800) 823-4937.
Warranty & Protection
- 12-month warranty covers manufacturing defects
- 30-day return window for unopened units
- Free technical verification before ordering
- Each pump pressure tested before shipment
Ordering Options
Order online for immediate processing. Phone orders welcome at (800) 823-4937.
Net 30 terms available for approved accounts.
Volume pricing available on orders of 4 or more units.
Support & Documentation
- Installation guide included with every shipment
- Technical drawings and specifications available—see our vane pumps resource page for downloads
- Cross-reference guides for common brands
- Phone support: Monday-Friday, 7 AM – 5 PM MST
Questions? Call our specialists: (800) 823-4937
Product Selection Guide
For detailed cross-referencing, consult our V101B2B1C20R and related Vickers replacement pumps.
All models are part of our single stage vane pumps series for mobile and industrial applications.
All five FluiDyne V101 models listed are direct Vickers V10 replacements with 100% interchangeability, sharing the same displacement (0.60 in³/r), pressure (2500 PSI), and mounting (SAE ‘A’ 2-bolt flange). The key differences between these models are shaft type, port orientation, and rotation direction, which directly affect installation compatibility and system design in compact machinery or mobile hydraulics.
| Model Number | Flow Rate | Max Pressure | Displacement | Mounting |
|---|---|---|---|---|
| V101P3P11B20R (Current) | Contact us | 9-Tooth Splined Shaft | 9.8 cm³/r (0.60 in³/r) | 1/2″ NPT Thread |
| V101P3P0C20L024 | Contact us | Shaft code 0 | 9.8 cm³/r (0.60 in³/r) | 1/2″ NPT Thread |
| V101P3P11A20L | Contact us | 9-Tooth Splined Shaft | 9.8 cm³/r (0.60 in³/r) | 1/2″ NPT Thread |
| V101P3P11A20R | Contact us | 9-Tooth Splined Shaft | 9.8 cm³/r (0.60 in³/r) | 1/2″ NPT Thread |
| V101P3P11C20L | Contact us | 9-Tooth Splined Shaft | 9.8 cm³/r (0.60 in³/r) | 1/2″ NPT Thread |
Not sure which shaft type or port orientation fits your needs? Review our pumps with integral valves for integrated solutions.
Key Differences
Rotation Direction
Difference: Models are available in right-hand (clockwise) or left-hand (counter-clockwise) rotation.
Selection Guide: Match the pump rotation to your system’s drive shaft direction: Use ‘R’ models for right-hand (clockwise), ‘L’ models for left-hand (counter-clockwise) applications.
Port Position
Difference: Port positions are either 90° counter-clockwise from inlet, inline with inlet (0°), or opposite from inlet (180°).
Selection Guide: Select port orientation based on your plumbing layout: Inline (0°) for straight-through connections, 90° for side exits in tight spaces, and 180° when ports must be opposite each other.
Shaft Type
Difference: Most models use a 9-tooth splined shaft; one model uses a shaft code 0 (details not fully specified but likely a keyed shaft).
Selection Guide: Splined shafts are preferred for high-torque or heavy-duty couplings. Match the shaft style to your drive coupling for optimal fit and longevity.
Model Number Patterns
Difference: The 3rd and 4th characters (e.g., P3P1 or P3P0) and the end letter (R or L) indicate shaft/port/rotation configuration.
Selection Guide: Model numbers ending in ‘R’ are right-hand rotation; ‘L’ are left-hand. ‘A’ or ‘C’ in the middle denotes port position (A=180°, C=0°), making it easier to match to your machine’s requirements.
Quick Selection Guide
If you need: Right-hand (clockwise) rotation with 90° port position
Choose: V101P3P11B20R
Because: Port is 90° counter-clockwise from inlet, right-hand rotation, 9-tooth splined shaft.
If you need: Left-hand (counter-clockwise) rotation with inline ports (0°)
Choose: V101P3P0C20L024 or V101P3P11C20L
Because: Both offer inline port orientation and left-hand rotation—select based on required shaft style.
If you need: Right-hand (clockwise) rotation with ports opposite inlet (180°)
Choose: V101P3P11A20R
Because: This model offers right-hand rotation and 180° port orientation for straightforward replacement.
If you need: Left-hand (counter-clockwise) rotation with ports opposite inlet (180°)
Choose: V101P3P11A20L
Because: This matches left-hand systems requiring opposite port orientation.
Compatibility: All models feature SAE ‘A’ 2-bolt flange mounting, 1″ NPT inlet, and 1/2″ NPT outlet for direct replacement in Vickers V10 installations. Displacement and pressure ratings are identical, ensuring easy interchangeability.
All recommended models belong to our trusted vane pumps applications family, ensuring proven interchangeability with Vickers.
For help choosing the best model for your equipment or application, call our hydraulic specialists at (800) 823-4937 (Mon-Fri, 7 AM – 5 PM MST). Same-day shipping is available for in-stock items, and all pumps include a 12-month warranty. Volume pricing starts at 4 units.
Fluidyne V101 V101P3P11B20R – 3 GPM (0.60 in³/r), 2500 PSI, SAE A 2-Bolt Flange, 9-Tooth Splined Shaft – Direct Vickers V10 Replacement
$261.80
In stock
No sales tax
Expected delivery Sep 12 - Sep 16
