Stop losing $1,200 daily to hydraulic pump failures. The V10F1P4P11C3F20R matches Vickers performance with 100% interchangeability across 3,100 documented installations. Most operators see 6-month ROI with same-day shipping and expert phone support at (800) 823-4937.
Technical Specifications
Flow Performance
At 4 GPM, the V10F1P4P11C3F20R delivers the ideal flow for small loaders and compact hydraulic systems. This matches Vickers V10 requirements exactly. Operators save up to 3.5 hours weekly versus generic replacements.Performance stays consistent from 1,200 to 3,400 RPM. After 2,000 hours, efficiency remains at 94%. Comparable off-brand vane pumps drop to 82% by this point.Installation takes just 35 minutes with standard wrenches. The 2-bolt SAE “A” flange fits most compact tractors and utility machines without adapters. ISO 32-68 oil compatibility prevents premature seal wear.
Efficiency & Durability
Maintains consistent efficiency throughout operational lifespan.
Features and Benefits
- Direct Vickers Interchange: Model code and mounting match Vickers V10 exactly. Fleet managers report zero retrofit costs.
- Max Pressure: 2,500 PSI rated for heavy-duty cycles. Maintenance teams note 22% fewer failure incidents per year.
- Same-Day Shipping: Orders ship same day from Northern Hydraulics. Downtime reduced by 1.6 days on average.
Operational Information
Cold starts succeed at 10°F. Continuous operation is rated for 2,000 hours at 2,500 PSI. Handles 15% overload spikes without seal damage. Replace when efficiency drops below 90%.
Quality Assurance
Manufactured to the highest standards with rigorous quality control throughout the production process.
For technical support and assistance, contact our hydraulics specialists at (800) 823-4937.
| Weight | 93.0 lbs |
|---|---|
| Dimensions | 20 × 20 × 15 in |
| Pump Mounting Flange | 2-Bolt Flange (SAE "A" size) |
| Manufacturer | Fluidyne Fluid Power |
| Pumps Drive Shaft | 3/4" Straight Shaft with Key (1.75" extension) |
| Pumps Rotation | Right-Hand (Clockwise) |
| Pumps Max Pressure | 2500 psi |
| Pumps Rated Speed | 1200 RPM |
| Pumps Max Speed | 3400 RPM |
| Pumps Displacement | 13.1 cm³/r (0.80 in³/r) |
| Pumps Ports In | G1" BSPP Straight Thread |
| Pumps Ports Out | G1/2" BSPP Straight Thread |
Compatibility & Applications
Direct Replacement Information
The Fluidyne V10F1P4P11C3F20R directly replaces Vickers replacement pumps in systems requiring 13.1 cm³/r (0.80 in³/r) displacement and up to 2500 PSI operating pressure. This model is fully interchangeable with Vickers and follows SAE J744 mounting standards for straightforward installation..
- Mounting Pattern: SAE ‘A’ 2-bolt
- Inlet Port: G1″ BSPP
- Outlet Port: G1/2″ BSPP
Common Applications
Commonly used in mobile hydraulics, auxiliary power units, compact equipment. For more real-world examples and application stories, see our vane pumps case studies.
- mobile hydraulics
- auxiliary power units
- compact equipment
Important: Verify pump model V10F1P4P11C3F20R matches your existing Vickers unit before ordering. For technical assistance, contact (800) 823-4937.
Product Selection Guide
All five FluiDyne V10 Series models provide the same flow rate, displacement, pressure rating, and mounting, but differ in flow control GPM, relief valve setting, port position, shaft rotation, and minor shaft configurations. Compare additional pumps with integral valves for specialized applications. These differences determine suitability for varying hydraulic circuit requirements, installation layouts, and safety needs.
?? Important: The specifications shown are for reference and comparison purposes. Always verify specifications with the official manufacturer documentation or contact our technical team at (800) 823-4937 before ordering to ensure compatibility with your application. We cannot accept returns due to specification mismatches.
| Model Number | Flow Rate | Max Pressure | Displacement | Mounting |
|---|---|---|---|---|
| V10F1P4P11C3F20R (Current) | 4.2 GPM | 2500 PSI | 13.1 cm³/r (0.80 in³/r) | 2-Bolt Flange (SAE “A” size) |
| V10F1P4P11A2E20R – FluiDyne V10 Pump (13.1 cm³/r (0.80 in³/r), 4.2 GPM, 1250 PSI Relief) | 4.2 GPM | 2500 PSI | 13.1 cm³/r (0.80 in³/r) | 2-Bolt Flange (SAE “A” size) |
| V10F1P4P11A3D20R | 4.2 GPM | 2500 PSI | 13.1 cm³/r (0.80 in³/r) | 2-Bolt Flange (SAE “A” size) |
| V10F1P4P11A4D20L | 4.2 GPM | 2500 PSI | 13.1 cm³/r (0.80 in³/r) | 2-Bolt Flange (SAE “A” size) |
| V10F1P4P11A4D20R | 4.2 GPM | 2500 PSI | 13.1 cm³/r (0.80 in³/r) | 2-Bolt Flange (SAE “A” size) |
Key Differences
Flow Control GPM
Difference: Models offer flow control settings of 2, 3, or 4 GPM
Selection Guide: Select a model with a flow control setting matching your system’s desired output: choose 2 GPM (V10F1P4P11A2E20R) for lower flow circuits, or 4 GPM (V10F1P4P11A4D20L/R, V10F1P4P11C3F20R) for maximum available flow
Relief Valve Setting
Difference: Available relief settings: 1000 PSI, 1250 PSI, or 1500 PSI
Selection Guide: Match relief valve to your system’s maximum safe working pressure. For systems requiring higher overpressure protection, select 1500 PSI (V10F1P4P11C3F20R); for lower limits, choose 1000 PSI (V10F1P4P11A3D20R, V10F1P4P11A4D20L/R)
Port Position
Difference: Port orientation is either inline (0°) or opposite (180°) from inlet
Selection Guide: Choose inline ports (V10F1P4P11C3F20R) for straightforward plumbing where space is limited; select opposite ports (all others) when routing lines to the opposite side is preferred
Shaft Rotation
Difference: Available in right-hand (clockwise) or left-hand (counter-clockwise)
Selection Guide: Match pump rotation to motor direction: right-hand (R) for standard engines, left-hand (L) for reverse-driven systems (V10F1P4P11A4D20L is the only left-hand model here)
Flow Control vs Relief Valve Combination
Difference: Some models combine higher flow control with lower relief, others balance both higher
Selection Guide: For applications needing higher flow with tighter pressure safety, select V10F1P4P11C3F20R (4 GPM, 1500 PSI); for lower flow and more conservative pressure, opt for V10F1P4P11A3D20R (3 GPM, 1000 PSI)
Quick Selection Guide
If you need: Maximum flow control (4 GPM) and highest relief setting (1500 PSI)
Choose: V10F1P4P11C3F20R
Because: Provides highest flow and overpressure safety; ideal for demanding small hydraulic circuits
If you need: Lower flow (2 GPM) with moderate relief (1250 PSI)
Choose: V10F1P4P11A2E20R
Because: Best for delicate or small-capacity circuits where excess flow could cause problems
If you need: Standard flow (3 GPM) and lower maximum pressure (1000 PSI)
Choose: V10F1P4P11A3D20R
Because: Suitable for medium-capacity circuits with lower pressure requirements
If you need: Left-hand (counter-clockwise) rotation
Choose: V10F1P4P11A4D20L
Because: Only model in this group designed for reverse rotation motors
If you need: Right-hand rotation and standard max flow (4 GPM) at lowest pressure (1000 PSI)
Choose: V10F1P4P11A4D20R
Because: Fits installations needing the highest flow among these with standard rotation but limited to 1000 PSI relief
Compatibility: All V10 models listed are 100% interchangeable with Vickers V10 pumps applications, use SAE ‘A’ 2-bolt flanges, and share G1″/G1/2″ BSPP ports for seamless replacement or upgrade.
For application-specific selection, cross-referencing, or troubleshooting, Northern Hydraulics’ hydraulic specialists are available Mon-Fri, 7 AM – 5 PM MST at (800) 823-4937 applications. For a complete range of hydraulic pumps and technical resources, visit our main product family page.
Purchasing Information
Availability & Delivery
Most hydraulic pumps ship within 1-2 business days. Made-to-order items typically require 5-7 business days.
For current availability on V10F1P4P11C3F20R, call (800) 823-4937.
Warranty & Protection
- 12-month warranty covers manufacturing defects
- 30-day return window for unopened units
- Free technical verification before ordering
- Each pump pressure tested before shipment
Ordering Options
Order online for immediate processing. Phone orders welcome at (800) 823-4937.
Net 30 terms available for approved accounts.
Volume pricing available on orders of 4 or more units.
Support & Documentation
- Installation guide included with every shipment
- Technical drawings and specifications available
- Cross-reference guides for common brands
- Phone support: Monday-Friday, 7 AM – 5 PM MST
Questions? Call our specialists: (800) 823-4937
Fluidyne V10 V10F1P4P11C3F20R Valve | Vickers V10 Replacement 4 GPM | 3 PSI | G1/2″ BSPP Straight Thread | 3/4″ Keyed Shaft
