• Product Name: 3.37″ Bore x 16″ Stroke Hydraulic Cylinder
• Bore Diameter: 3.37 inches
• Rod Diameter: 1.5 inches
• Overall Length: 26.81 inches
• Stroke Length: 16 inches
• Extended Length: 41 inches
• Retracted Length: 25 inches
• Pressure Rating: 3500 PSI
• Column Load Capacity: 21,000 LBs
• Oil Volume: 1.96 QTs
• Rod Type: Chrome Plated
• Rod End Type: Narrow Tube
• Action Type: Double Acting
• Style: Welded
• Ports: SAE 8

NOTE! The chrome-plated rod is NOT induction hardened (temperature treated). Possible bent rod is a result of misuse (wrong measurements or type of application), such cases are not covered under warranty!

Experience heavy-duty performance with our 3.37″ Bore x 16″ Stroke Hydraulic Cylinder, specifically designed for those requiring dependability under pressure. With a high load capacity of 21,000 LBs and a pressure rating of 3500 PSI, this double-acting cylinder is perfect for demanding applications where robust performance and longevity are a must.

Manufactured by Northern Hydraulics, this high-quality hydraulic cylinder promises durability and reliability, making it an excellent replacement for other cylinders you may have in use.

Key Benefits:

• Fits various application requirements due to its versatile design and robust construction.
• Welded style provides enhanced stability and performance.
• Compatible with a range of equipment, ensuring easy integration into existing hydraulic systems.
• Designed for optimum efficiency, enabling effective operation within its specifications.

Same-Day Shipping: Place your order by 3 pm, and we will ship it the same day (excluding weekends and holidays).

Free Ground Shipping: We offer free ground shipping within the continental U.S.

Tariff-FREE cylinders:

Made in Europe.

If you need assistance choosing the proper hydraulic cylinder replacement, do not hesitate to contact us at (800) 823-4937.
