2″ Bore X 24″ Stroke Welded Cylinder: Tang style base end, 3500 PSI, SAE #6 ports

Specifications
Weight 26 lbs
Dimensions 36 × 4 × 4 in
Cylinder Bore

2"

Cylinder Stroke Ranges

24

Cylinder Extended Length

57

Cylinder Style

Welded Tang

Cylinder Retracted Length

33

Cylinder Port Size

ORB – 6

Manufacturers

Northern Hydraulics

Overview

2″ Bore X 24″ Stroke Welded Tang Double Acting Hydraulic Cylinder

Double-acting Tang welded hydraulic cylinder rated to 3500 PSI. Ideal for ag-style front end loader replacement cylinders.  Tang hydraulic cylinders are designed with a rigid welded end, to work in harsh conditions and fit most applications. Base end will be pivoting, providing a larger range of motion.

Product Features:

Tube: High tensile, honed
Rod: Polished, chrome plated
Gland: Precision threaded with wear rings
Piston Seals: Compact 5-component seals
Rod Seals: Standard U-cup polyurethane rod seal with inner O-ring, POM-C wear rings and polyurethane wiper
Pressure: 3500 PSI


Product Specifications:

2″ Bore
24″ Stroke
1.25″ Diameter Rod
1″ Pin Hole Diameter

33″ Retracted Pin to Pin Distance
57″ Extended Length
SAE 6 Port Size
8,400 lb. Column Load
27 lb. Cylinder Weight

Free Shipping Img

Available on this hydraulic cylinder.

Offer applies to in stock items shipping within the continental US.

Please call 1-800-823-4937 for multiple quantity discounts or expedited shipping.

2" Bore X 24" Stroke Welded Tang Hydraulic Cylinder

0.0 (0)
SKU: WTG2x24
0.0 out of 5 Read reviews
5 star
0
4 star
0
3 star
0
2 star
0
1 star
0

$254.10 -10% $231.00

In stock Expected delivery between Apr 25 - May 02
13 sold in the last 24 hours
No sales tax
Free shipping
