Get the 2.5" bore x 14" stroke hydraulic cylinder at 2500 PSI, designed for heavy-duty performance. Enjoy free shipping and a 2-year warranty!
Specifications
| Weight | 22 lbs |
|---|---|
| Dimensions | 26 × 5 × 5 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 14 |
| Cylinder Extended Length | 38.25 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 24.25 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.87 in |
| Cylinder Rod Diameter | 1.125 in |
| Cylinder Overall Length | 26.25 in |
| Cylinder PSI | 2500 PSI |
| Cylinder Column Load | 12,270 lbs |
| Cylinder Oil Volume | 1.19 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Clevis |
| Cylinder Action | Double Acting |
Overview
- Specifications:
- Bore Diameter: 2.5 inches
- Stroke Length: 14 inches
- Overall Length: 26.25 inches
- Extended Length: 38.25 inches
- Retracted Length: 24.25 inches
- Rod Diameter: 1.125 inches
- PSI Rating: 2500 PSI
- Column Load: 12,270 lbs
- Oil Volume: 1.19 QTs
- Rod Type: Chrome Plated
- Rod End: Clevis
- Action: Double Acting
- Style: Welded
- Ports: SAE 8
- Features:
- Designed to withstand heavy-duty applications with a column load capacity of 12,270 lbs.
- Durable build quality with a chrome-plated rod for increased corrosion resistance.
- Double acting action ensures optimal performance and efficiency.
- Versatile installation options with the clevis rod end for easy integration into various systems.
- Usage Information:
- Shipping:
- Warranty:
- Contact Us:
This hydraulic cylinder is perfect for industrial machinery, agricultural equipment, or construction vehicles, ensuring power and reliability.
Same-Day Shipping available for orders placed by 3 PM (excluding weekends and holidays).
Enjoy peace of mind with a 2-year warranty covering manufacturing defects.
If you need assistance choosing the right hydraulic cylinder, please contact us at (800) 823-4937.
2.5 in Bore x 14 in Stroke Hydraulic Cylinder | Northern Hydraulics
SKU: WBCN2.5x14
$213.64 -12% $188.00
1+
$ 188.00/piece
4+
$ 178.60/piece
-5%
8+
$ 169.20/piece
-10%
32 viewed in the last 24 hours
In stock Expected delivery between Oct 06 - Oct 13
No sales tax
Free shipping
