1.75″ bore x 14″ stroke hydraulic cylinder, 3500 PSI, double-acting, cross tube design, heavy-duty, and perfect for various applications. Buy now!
Specifications
| Weight | 16 lbs |
|---|---|
| Dimensions | 26 × 4 × 4 in |
| Cylinder Bore | 1.75" |
| Cylinder Stroke Ranges | 14 |
| Cylinder Extended Length | 42.5 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 28.5 |
| Cylinder Port Size | ORB – 6 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.13 in |
| Cylinder Rod Diameter | 1 in |
| Cylinder Overall Length | 28.75 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 5,150 lbs |
| Cylinder Oil Volume | 0.58 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
- Product Name: 1.75″ Bore x 14″ Stroke Hydraulic Cylinder
- Outer Diameter: 2.13 in
- Rod Diameter: 1 in
- Overall Length: 28.75 in
- Extended Length: 42.5 in
- Retracted Length: 28.5 in
- Pressure Rating: 3500 PSI
- Column Load: 5,150 LBs
- Oil Volume: 0.58 QTs
- Rod Type: Chrome Plated
- Rod End: Cross Tube
- Action: Double Acting
- Style: Welded
- Ports: SAE 6
Key Features and Benefits:
- Durable construction ensures longevity and reliability.
- Double-acting design provides improved efficiency in operations.
- Capable of handling high loads, making it suitable for various applications.
- Cross-tube rod end simplifies installation and maintenance.
- Perfect replacement for older or discontinued hydraulic cylinders.
Usage Information:
To utilize the hydraulic cylinder, ensure proper installation according to your machinery specifications. Regular maintenance checks are recommended to ensure optimal performance.
Shipping Information:
Same-Day Shipping: All orders made until 3 PM will be shipped the same day (except on weekends and holidays).
Free Ground Continental U.S. Shipping on all orders.
If you need assistance or have any questions regarding your hydraulic cylinder selection, please do not hesitate to contact us at (800) 823-4937.
