Double acting 19.75" stroke hydraulic cylinder with 3500 PSI capacity. Rugged construction, 9400 lbs load capacity, and made by Northern Hydraulics. Order now!
Specifications
| Weight | 23 lbs |
|---|---|
| Dimensions | 31 × 4 × 4 in |
| Cylinder Bore | 2" |
| Cylinder Stroke Ranges | 19.75 |
| Cylinder Extended Length | 46.125 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 26.375 |
| Cylinder Port Size | ORB – 6 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.37 in |
| Cylinder Rod Diameter | 1.25 in |
| Cylinder Overall Length | 28.375 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 9,400 lbs |
| Cylinder Oil Volume | 1.07 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
- Product Name: WLDN2x19.75 Double Acting Hydraulic Cylinder
- Stroke Length: 19.75 inches
- Extended Length: 46.125 inches
- Retracted Length: 26.375 inches
- Bore Diameter: 2.37 inches
- Rod Diameter: 1.25 inches
- Pressure Rating: 3500 PSI
- Column Load Capacity: 9,400 lbs
- Oil Volume: 1.07 quarts
- Rod Type: Chrome Plated
- Rod End Type: Cross Tube
- Style: Welded
- Ports: SAE 6
This welded double acting hydraulic cylinder is designed for heavy-duty performance, making it an excellent choice for various industrial applications. Whether you need it for construction, machinery, or other hydraulic tasks, this cylinder delivers reliability and strength.
Unique Features:
- Sturdy design to handle high-pressure tasks.
- Precision honed cylinder to maximize performance and longevity.
- Chrome-plated rod enhances durability and resistance to wear and corrosion.
- Cross tube rod end allows for versatile mounting options.
Usage Instructions:
- Ensure proper mounting and alignment during installation.
- Check fluid levels and ensure the hydraulic system is free from leaks.
- Operate within the specified pressure ratings for optimal performance.
Care and Maintenance:
- Regularly inspect for any signs of wear or damage.
- Maintain proper hydraulic fluid levels and quality.
- Store in a clean and dry environment when not in use.
This hydraulic cylinder is a proud product of Northern Hydraulics, crafted with precision and engineered for high performance in demanding environments. Explore the possibilities this cylinder can offer for your hydraulic needs.
Order now to take advantage of our fast shipping options and enhance your equipment with this reliable hydraulic cylinder!
Welded 19.75 Inch Stroke Hydraulic Cylinder | Northern Hydraulics
SKU: WLDN2x19.75
$235.11 -6% $221.00
1+
$ 221.00/piece
4+
$ 209.95/piece
-5%
8+
$ 198.90/piece
-10%
34 viewed in the last 24 hours
In stock Expected delivery between Oct 06 - Oct 13
No sales tax
Free shipping
