2.5" bore x 16" stroke hydraulic cylinder 3500 PSI, 14,700 lbs load capacity. Durable, welded construction with chrome plated rod. Free shipping!
Specifications
| Weight | 25 lbs |
|---|---|
| Dimensions | 28 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 16 |
| Cylinder Extended Length | 40 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 24 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.87 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 25.37 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 14,700 lbs |
| Cylinder Oil Volume | 1.36 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Pin Hole |
| Cylinder Action | Double Acting |
Overview
The 2.5 Bore x 16 Stroke Hydraulic Cylinder by Northern Hydraulics is engineered to offer robust performance and reliability for all your hydraulic needs. With a powerful bore and a rugged design, this double-acting cylinder is perfect for heavy lifting tasks.
- Bore Diameter: 2.5 inches
- Stroke Length: 16 inches
- Operating Pressure: 3500 PSI
- Column Load Capacity: 14,700 lbs
- Oil Volume: 1.36 quarts
- Rod Type: Chrome plated for enhanced durability
- Action: Double acting for efficient operation
- Ports: SAE 8 for easy installation
- Overall Length: 25.37 inches (Extended Length: 40 in, Retracted Length: 24 in)
- Style: Welded construction for increased strength
NOTE: Chrome-plated rod is NOT induction hardened. Possible bent rod is a result of misuse (improper measurements or application type), and such cases are not covered under warranty!
Same-Day Shipping: All orders placed before 3 pm will be shipped the same day (excluding weekends and holidays).
Free Ground Continental US Shipping!
Tariff-FREE cylinders made in Europe!
If you require assistance selecting the appropriate hydraulic cylinder replacement, please do not hesitate to contact us at (800) 823-4937.
2.5 Bore x 16 Stroke Hydraulic Cylinder, Double Acting | Northern Hydraulics
