1.5″ Bore X 20″ Stroke Welded Cylinder: Tang style base end, 3500 PSI, SAE #6 ports

Specifications
Weight 16 lbs
Dimensions 32 × 4 × 4 in
Cylinder Bore

1.5"

Cylinder Stroke Ranges

20

Cylinder Extended Length

49

Cylinder Style

Welded Tang

Cylinder Retracted Length

29

Cylinder Port Size

ORB – 6

Manufacturers

Northern Hydraulics

Overview

WELDED TANG DOUBLE ACTING HYDRAULIC CYLINDER 1.5″ BORE X 20″ STROKE

Double acting welded Tang hydraulic cylinder rated to 3500 PSI.  Ideal for ag-style front end loader replacement cylinders.  Tang cylinders are designed with a rigid welded end, to work in harsh conditions and fit most applications. Base end will be pivoting, providing a larger range of motion.

Product Features:

Tube: High tensile, honed
Rod: Polished, chrome plated
Gland: Precision threaded with wear rings
Piston Seals: Compact 5-component seals
Rod Seals: Standard U-cup polyurethane rod seal with inner O-ring, POM-C wear rings and polyurethane wiper
Pressure: 3500 PSI

Product Specifications:

1.5″ Bore
20″ Stroke
1″ Diameter Rod
0.75″ Pin Hole Diameter

29″ Retracted Pin to Pin Distance
49″ Extended Length
SAE 6 Port Size
5,300 lb. Column Load
18 lb. Cylinder Weight

Free Shipping Img

Available on this hydraulic cylinder.

Offer applies to in stock items shipping within the continental US.

Please call 1-800-823-4937 for multiple quantity discounts or expedited shipping.

1.5″ Bore X 20″ Stroke Welded Tang Hydraulic Cylinder
