Introducing the WSEN2.5×16 Hydraulic Cylinder, a robust solution designed for heavy-duty applications. With an impressive capacity of 3500 PSI and a stroke length of 16 inches, this double acting hydraulic cylinder is engineered to perform under pressure. Whether you’re replacing, upgrading, or installing a new unit, the WSEN2.5×16 is built to handle your demanding tasks with ease.

• Outer Diameter: 2.87 inches
• Rod Diameter: 1.5 inches
• Overall Length: 28.87 inches
• Stroke Length: 16 inches
• Extended Length: 42 inches
• Retracted Length: 26 inches
• Column Load: 14,700 lbs
• Oil Volume: 1.36 quarts
• Rod Type: Chrome Plated
• Rod End: Spherical Bearings
• Style: Welded
• Ports: SAE 8
• Weight: 28 lbs

Key Features and Benefits:

• Designed for double acting action ensuring consistent performance.
• Built to withstand a high pressure rating of 3500 PSI.
• Ideal for various industrial applications, including construction and agricultural machinery.
• Durable construction with chrome plated rod for enhanced protection.
• Efficient oil volume capacity allows for effective hydraulic performance.

Usage Instructions:

Ensure that the cylinder is installed correctly, following all manufacturer guidelines. Regularly check the seals and connections for leaks. Use the appropriate hydraulic oil as specified in the user manual.

All our hydraulic cylinders, including the WSEN2.5×16, are backed by a 2-year warranty, providing you peace of mind with your investment. Enjoy free ground shipping within the Continental US on all orders.

Upgrade your hydraulic system today with the WSEN2.5×16 hydraulic cylinder! For assistance or inquiries, please reach out at (800) 823-4937.
