Home » Hydraulics Shop » Hydraulic Cylinders » Welded Cylinders: Clevis Mount » 2.5 Bore x 24 Stroke Hydraulic Cylinder | Northern Hydraulics

WCL_Long500x500O

2.5" bore x 24" stroke welded hydraulic cylinder with 3500 PSI. Heavy-duty performance, 2-year warranty, free ground shipping across Continental US.

Specifications

Weight	33 lbs
Dimensions	36 × 5 × 5 in
Cylinder Bore	2.5"
Cylinder Stroke Ranges	24
Cylinder Extended Length	58.25
Cylinder Style	Welded
Cylinder Retracted Length	34.25
Cylinder Port Size	ORB – 8
Manufacturers	Northern Hydraulics
Cylinder Outer Diameter	2.87 in
Cylinder Rod Diameter	1.25 in
Cylinder Overall Length	36.25 in
Cylinder PSI	3500 PSI
Cylinder Column Load	7,900 lbs
Cylinder Oil Volume	2.04 qts
Cylinder Rod Type	Chrome Plated
Cylinder Rod End	Clevis
Cylinder Action	Double Acting

Overview

Introducing the WCLN2.5×24 Hydraulic Cylinder, engineered for excellence in hydraulic performance. With a robust construction and a variety of applications, this hydraulic cylinder is ideal for heavy-duty tasks, making it a reliable choice for professionals and enthusiasts alike.

Dimensions: 2.5" bore x 24" stroke.
Operating Pressure: 3500 PSI.
Overall Length: 36.25" extended length of 58.25" and retracted length of 34.25".
Weight: 33 lbs for stable positioning.
Port Size: SAE 8 for versatile applications.
Rod Type: Chrome Plated for enhanced durability.
Rod End: Clevis design for easy integration.
Column Load: Capable of supporting loads up to 7,900 lbs.
Oil Volume: Requires 2.04 quarts of oil for optimal operation.
Style: Welded for superior structural integrity.

This double-acting hydraulic cylinder is designed to handle rigorous tasks across various industries. Whether you are operating a front-end loader, agricultural machinery, or material handling equipment, it’s built to provide reliable and efficient performance.

Additional Information:
Same-Day Shipping: All orders placed before 3 PM will be shipped on the same day (excluding weekends and holidays).
Free Ground Continental US Shipping!
Made in Europe.

If you’re uncertain about which hydraulic cylinder replacement you need, please don’t hesitate to reach out to us at (800) 823-4937 for assistance.
