3.5″ Bore X 48″ Stroke Tie Rod Cylinder

Specifications

Weight	93 lbs
Dimensions	60 × 6 × 6 in
Cylinder Bore	3.5"
Cylinder Stroke Ranges	48
Cylinder Extended Length	106.25
Cylinder Style	Tie-Rod
Cylinder Retracted Length	58.25
Cylinder Port Size	ORB – 8
Manufacturers	Northern Hydraulics

Overview

How to Measure

Hydraulic Cylinders FAQ

Hydraulic Cylinders Identify/Terms

3-1/2″ x 48″ Tie Rod Cylinder

3-1/2″ Diameter Bore

48″ Stroke length

1.5″ Diameter Rod

#8 SAE Ports

Clevis Ends w/1″ Steel Pins

58.25″ Retracted Pin to Pin Distance

106.25″ Extended Length

2500 PSI

Shipping Weight is 93 lbs

B211389C

3-1/2" Bore x 48" Stroke Tie Rod Cylinder

Name: 3-1/2" Bore x 48" Stroke Tie Rod Cylinder
Brand: Northern Hydraulics
SKU: TRC3.5X48 B
Availability: InStock

0.0 (0)

SKU: TRC3.5X48 B

0.0 out of 5 Read reviews

5 star

4 star

3 star

2 star

1 star

~~$484.62 -9%~~ $441.00

No sales tax

1+ $ 441.00/piece

4+ $ 418.95/piece -5% most popular

8+ $ 396.90/piece -10%

In stock Expected delivery between May 01 - May 08
