Home » Hydraulics Shop » Hydraulic Cylinders » Welded Cylinders: Clevis Mount » WCLN4x12 2" x 12" Hydraulic Cylinder | Northern Hydraulics

High-performance 2" diameter x 12" stroke hydraulic cylinder with 3500 PSI. Ideal for various applications, free shipping available.

Specifications

Weight	50 lbs
Dimensions	24 × 6 × 6 in
Cylinder Bore	4"
Cylinder Stroke Ranges	12
Cylinder Extended Length	34.25
Cylinder Style	Welded
Cylinder Retracted Length	22.25
Cylinder Port Size	ORB – 8
Manufacturers	Northern Hydraulics
Cylinder Outer Diameter	4.5 in
Cylinder Rod Diameter	2 in
Cylinder Overall Length	24.25 in
Cylinder PSI	3500 PSI
Cylinder Column Load	37,000 lbs
Cylinder Oil Volume	2.61 qts
Cylinder Rod Type	Chrome Plated
Cylinder Rod End	Clevis
Cylinder Action	Double Acting

Overview

Specifications:

Bore Diameter: 2 inches
Stroke: 12 inches
Overall Length: 24.25 inches
Extended Length: 34.25 inches
Retracted Length: 22.25 inches
Outer Diameter: 4.5 inches
PSI Rating: 3500 PSI
Column Load: 37,000 LBs
Oil Volume: 2.61 QTs
Rod Type: Chrome Plated
Rod End Type: Clevis
Action: Double Acting
Ports: SAE 8
Style: Welded

Features and Benefits:

Designed for high performance with a robust 3500 PSI rating, suitable for heavy-duty applications.
Double acting action for enhanced efficiency and reliability in operation.
Chrome plated rod ensures durability and resistance to wear, providing a longer service life.
Clevis rod end allows for versatile mounting options in various setups.
Ideal for use in construction, agriculture, and material handling environments.
Lightweight at 50 lbs, making it easy to handle during installation.

Same-Day Shipping: All orders made until 3 pm will be shipped the same day (except weekends and holidays).

Free Ground Continental US Shipping available.

Tariff-FREE cylinders.

Manufactured by Northern Hydraulics.

If you need assistance selecting the right hydraulic cylinder for your needs, please contact us at (800) 823-4937.

WCLN4x12 2" x 12" Hydraulic Cylinder | Northern Hydraulics
