Introducing the WCLN4x18 Welded Double Acting Hydraulic Cylinder, a high-performance hydraulic solution designed for heavy-duty applications. Capable of delivering exceptional power and reliability, this hydraulic cylinder is ideal for various industrial uses.

• Specifications:
• Outer Diameter: 4.5 inches
• Rod Diameter: 2 inches
• Overall Length: 30.25 inches
• Stroke Length: 18 inches
• Extended Length: 46.25 inches
• Retracted Length: 28.25 inches
• Pressure Rating: 3500 PSI
• Column Load Capacity: 37,000 LBs
• Oil Volume: 3.91 QTs
• Rod Type: Chrome Plated
• Action: Double Acting
• Rod End Type: Clevis
• Ports Type: SAE 8
• Style: Welded
• Durable Construction: The WCLN4x18 hydraulic cylinder is engineered with a robust welded style that ensures long-lasting performance in demanding conditions.
• Efficient Power Delivery: With a dual acting mechanism, this cylinder provides reliable and consistent power output, allowing for precise control in various applications.
• High Load Capacity: Designed to handle a substantial column load of 37,000 LBs, making it perfect for heavy machinery and equipment.
• Versatile Use: This hydraulic cylinder can be employed in numerous sectors, including construction, farming, and industrial manufacturing.
• Easy Installation: With its clevis rod end and standardized SAE 8 ports, the WCLN4x18 is compatible with a wide range of hydraulic systems and equipment.
• Free Shipping: Enjoy free ground shipping on all continental US orders when you purchase this hydraulic cylinder.

NOTE! The chrome-plated rod is NOT induction hardened (temperature treated). Misuse may result in a bent rod, which is not covered under warranty!

Same-Day Shipping: All orders made until 3 pm will be shipped the same day (except weekends and holidays).

Contact Information: For assistance in choosing the proper hydraulic cylinder replacement, do not hesitate to contact us at (800) 823-4937.
