2.5" bore x 16" stroke hydraulic cylinder 3500 PSI. Durable and reliable double acting cylinder with a 2-year warranty and free shipping in the Continental US.
| Manufacturer | MagisterHyd |
|---|---|
| Cylinder Style | Welded |
| Cylinder Rod Type | Chrome Plated |
| Cylinder PSI | 3,500 PSI |
| Cylinder Column Load | 14,700 lb |
| Cylinder Port Size | ORB – 8 |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 16 in |
| Cylinder Extended Length | 41 in |
| Cylinder Retracted Length | 25 in |
| Cylinder Outer Diameter | 2.87 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 26.69 in |
| Cylinder Oil Volume | 1.36 qts |
| Cylinder Rod End | Narrow Tube |
| Cylinder Action | Double Acting |
| Shipping weight | 28 lb |
| Package size | 28 × 4 × 4 in |
Product Overview
The WTGN2.5×16 Hydraulic Cylinder from Northern Hydraulics is designed for superior durability and performance. With a bore size of 2.5 inches and a 16-inch stroke, this double acting hydraulic cylinder can handle demanding applications with ease. Engineered for reliability, it features a robust construction ideal for various industrial and agricultural uses.
Key Features and Benefits
- Bore Size: 2.5 inches, maximizing hydraulic efficiency.
- Stroke Length: 16 inches, suitable for a wide range of applications.
- Pressure Rating: 3500 PSI, ensuring exceptional strength and reliability.
- Column Load: Capable of handling up to 14,700 lbs.
- Oil Volume: 1.36 quarts to meet operational requirements.
- Rod Type: Chrome-plated for improved wear resistance.
- Welded Style: Durability is enhanced with a welded body construction.
- Action: Double acting, providing effective movement in both directions.
- Port Configuration: SAE 8 ports for easy connectivity.
- Weight: 28 lbs, balancing robustness with portability.
Usage and Care Instructions
To ensure optimal performance, regularly check the hydraulic fluid levels and inspect the seals for any wear or damage. It is recommended to operate the cylinder within its specified pressure rating to prolong its lifespan. Avoid rapid movement that could lead to mechanical failures.
About the Northern Hydraulics Series
This cylinder is part of the Northern Hydraulics hydraulic series, known for high-quality manufacturing standards and reliable performance across various demanding conditions. Whether you need it for agriculture, construction, or general industrial use, you can count on our hydraulic cylinders to work effectively under pressure.
Purchase Information
Order Now! Take advantage of our 2-year warranty and free ground shipping across the Continental US. Enhance your workflow with our cutting-edge hydraulic solutions today!
If you need assistance selecting the proper hydraulic cylinder replacement, do not hesitate to contact us at (800) 823-4937.
Trusted Manufacturing Partnership
This hydraulic cylinder is proudly manufactured by our longtime partner, Magister Hydraulics, known for their exceptional craftsmanship and reliability. At Northern Hydraulics, we're honored to offer their proven designs under our own brand, ensuring you get the best of both worlds — OEM-grade performance backed by our dedicated support and service.
