• Bore Size: 2.5 inches
• Stroke Length: 26 inches
• Overall Length: 36.69 inches
• Extended Length: 61 inches
• Retracted Length: 35 inches
• Pressure Rating: 3500 PSI
• Column Load Capacity: 13,700 lbs
• Oil Volume: 2.21 QT
• Rod Diameter: 1.5 inches
• Rod Type: Chrome Plated
• Rod End: Narrow Tube
• Action: Double Acting
• Style: Welded Construction
• Ports: SAE 8

Introducing the 2.5 Bore x 26 Stroke Hydraulic Cylinder from Northern Hydraulics. Designed to withstand intense pressure, this heavy-duty double acting cylinder is perfect for various applications, delivering a robust performance that you can count on. With a remarkable capacity to handle up to 13,700 lbs of column load, this hydraulic cylinder is suitable for both industrial and construction tasks.

This cylinder features:

• Superior welded construction for enhanced durability and reliability.
• Chrome plated rod that minimizes wear, ensuring longevity.
• Designed for maximum performance under high-pressure conditions, up to 3500 PSI.
• Customizable options with multiple mounting configurations.
• Effective oil volume capacity of 2.21 QT for optimal functionality.

Usage Information: Ideal for use in hydraulic systems across various machinery and equipment. Always follow manufacturer guidelines for installation and operation to maximize your cylinder’s lifespan.

Same-Day Shipping: All orders processed before 3 PM are shipped the same day (excluding weekends and holidays).

Free Ground Shipping on all orders within the Continental US!

Tariff-FREE cylinders that ensure cost-effectiveness without compromising quality.

Made in Europe.

If you need assistance selecting the right hydraulic cylinder for your needs, don’t hesitate to contact us at (800) 823-4937.
