Get the 2.5" bore x 18" stroke hydraulic cylinder, rated 3500 PSI. Heavy-duty, double acting, perfect for industrial applications. Shop now!
Specifications
| Weight | 30 lbs |
|---|---|
| Dimensions | 30 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 18 |
| Cylinder Extended Length | 45 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 27 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.87 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 28.69 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 14,700 lbs |
| Cylinder Oil Volume | 1.53 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Narrow Tube |
| Cylinder Action | Double Acting |
Overview
- Specifications:
- Bore Diameter: 2.5 inches
- Stroke Length: 18 inches
- Overall Length: 28.69 inches
- Extended Length: 45 inches
- Retracted Length: 27 inches
- Rod Diameter: 1.5 inches
- Pressure Rating: 3500 PSI
- Column Load: 14,700 LB
- Oil Volume: 1.53 QTs
- Type: Double Acting
- Style: Welded
- Rod Type: Chrome Plated
- Rod End: Narrow Tube
- Ports: SAE 8
- Key Features:
- High-performance hydraulic cylinder designed for heavy loads
- Manufactured to withstand extreme pressure and conditions
- Versatile design suitable for various industrial applications
- Chrome plated rod ensures smooth operation and longevity
- Easy installation with SAE ports
- Usage Information:
- Shipping Information:
This hydraulic cylinder is perfect for use in hydraulic systems requiring high force output. Ideal for applications in construction, agriculture, and manufacturing. Ensure to follow the manufacturer’s guidelines for optimal performance and longevity.
Same-Day Shipping: All orders made until 3 PM will be shipped the same day (except weekends and holidays).
Free Ground Shipping: Within the Continental US.
Tariff-FREE cylinders.
Made in Europe.
If you need assistance choosing a proper hydraulic cylinder replacement, do not hesitate to contact us: (800) 823-4937
2.5 Bore x 18 Stroke Hydraulic Cylinder 3500 PSI | Northern Hydraulics
SKU: WTGN2.5x18
$264.52 -7% $246.00
