WCTN3x16 hydraulic cylinder: 3.37″ diameter, 16″ stroke, 3500 PSI. Durable design for heavy-duty applications, 21,000 LB column load. Order now!
| Weight | 30.0 lbs |
|---|---|
| Dimensions | 28 × 5 × 5 in |
| Cylinder Bore | 3" |
| Cylinder Stroke Ranges | 16 |
| Cylinder Extended Length | 40 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 24 |
| Cylinder Port Size | ORB – 8 |
| Manufacturer | Magister Hydraulics, MagisterHyd |
| Cylinder Outer Diameter | 3.37 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 25.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 21,000 lbs |
| Cylinder Oil Volume | 1.96 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
- Model: WCTN3x16
- Type: Double Acting Hydraulic Cylinder
- Outer Diameter: 3.37 in
- Rod Diameter: 1.5 in
- Stroke Length: 16 in
- Extended Length: 40 in
- Retracted Length: 24 in
- Pressure Rating: 3500 PSI
- Column Load Capacity: 21,000 LBs
- Oil Volume: 1.96 QTs
- Rod Type: Chrome Plated
- Rod End: Cross Tube
- Style: Welded
- Ports: SAE 8
- Weight: 30 LBs
Experience powerful performance with the WCTN3x16 Double Acting Hydraulic Cylinder from Northern Hydraulics. Engineered for heavy-duty applications, this cylinder is designed to handle demanding tasks with ease and efficiency.
Key features of the WCTN3x16 include:
- Enhanced durability with a chrome plated rod for strength and resistance to wear.
- Design suitable for a variety of applications, capable of supporting heavy loads.
- Easy installation with cross tube rod end allowing for versatile mounting options.
Made to last, the WCTN3x16 is perfect for industrial use, including hydraulic machinery and equipment. Its high pressure rating and column load capacity ensure it can tackle the toughest jobs. Maintain optimum performance with regular oil checks, ensuring a sufficient oil volume is used to prevent operation issues.
Order your WCTN3x16 Double Acting Hydraulic Cylinder today and take advantage of its exceptional performance. Need assistance? Call (800) 823-4937 for support!
Trusted Manufacturing Partnership
This hydraulic cylinder is proudly manufactured by our longtime partner, Magister Hydraulics, known for their exceptional craftsmanship and reliability. At Northern Hydraulics, we're honored to offer their proven designs under our own brand, ensuring you get the best of both worlds — OEM-grade performance backed by our dedicated support and service.
WCTN3x16 Double Acting Hydraulic Cylinder | Magister
$299.00
In stock
No sales tax
Free shipping
Expected delivery Sep 12 - Sep 16
Easy to install and works great
Handles every heavy load with ease
Shipped fast and was in stock, thanks!
Durable and strong, meets expectations
Solid performance under pressure
