High-quality 2.5″ bore x 36″ stroke hydraulic cylinder, double-acting, 3500 PSI. Ideal for heavy-duty applications. Order now for free shipping!
Specifications
| Weight | 46 lbs |
|---|---|
| Dimensions | 48 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 36 |
| Cylinder Extended Length | 80 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 44 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.875 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 45.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 8,400 lbs |
| Cylinder Oil Volume | 3.06 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
- Product Name: 2.5 Bore x 36 Inch Hydraulic Cylinder
- Bore Size: 2.5 inches
- Stroke Length: 36 inches
- Overall Length: 45.5 inches
- Extended Length: 80 inches
- Retracted Length: 44 inches
- Rod Diameter: 1.5 inches
- Working Pressure: 3500 PSI
- Column Load: 8,400 LBs
- Oil Volume: 3.06 QTs
- Rod Type: Chrome Plated
- Rod End Type: Cross Tube
- Action: Double Acting
- Style: Welded
- Ports: SAE 8
This high-performance hydraulic cylinder is designed for durability and efficiency. It’s perfect for various applications including construction, agriculture, and machinery. The double-acting feature allows for effective pushing and pulling, making it a versatile tool for your hydraulic needs.
Key Benefits:
- Robust Construction: Built to withstand heavy-duty conditions.
- High Performance: Operates at 3500 PSI for optimal power delivery.
- Versatile Fit: Compatible with various machinery and suitable for a range of applications.
- Efficient Design: Chrome plated rod enhances durability and reduces wear.
Usage Instructions:
Ensure proper installation by aligning the cylinder correctly with your machinery’s mounting points. Always follow safety guidelines when operating hydraulic equipment.
With a commitment to quality, this hydraulic cylinder comes with a 2-year warranty, providing peace of mind for your investment.
Order now and take advantage of FREE ground shipping within the Continental US!
Note: In case you need assistance choosing the right hydraulic cylinder, feel free to reach out to us at (800) 823-4937.
