Shop the WCTN2.5×16 double acting hydraulic cylinder, 2.875" outer diameter, 3500 PSI pressure, and 16" stroke. Durable, effective performance for heavy-duty applications.
Specifications
| Weight | 25 lbs |
|---|---|
| Dimensions | 28 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 16 |
| Cylinder Extended Length | 40 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 24 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.875 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 25.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 14,700 lbs |
| Cylinder Oil Volume | 1.36 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
The WCTN2.5×16 Double Acting Hydraulic Cylinder is engineered for heavy-duty performance, built to handle tough applications with ease. Featuring a robust design and precision craftsmanship, this hydraulic cylinder ensures reliability and efficiency in various environments.
- Specifications:
- Bore Diameter: 2.875 in
- Rod Diameter: 1.5 in
- Overall Length: 25.5 in
- Stroke Length: 16 in
- Extended Length: 40 in
- Retracted Length: 24 in
- Pressure Rating: 3500 PSI
- Column Load: 14,700 LBs
- Oil Volume: 1.36 QTs
- Rod Type: Chrome Plated
- Rod End: Cross Tube
- Action: Double Acting
- Port Type: SAE 8
- Style: Welded
- Benefits:
- High durability due to welded construction and chrome plating.
- Efficient operation with double-action mechanism for rapid extension and retraction.
- Designed for heavy lifting with a column load capacity of 14,700 LBs.
- Compatible with various applications such as construction, farming, and industrial machinery.
- Pressure-rated for demanding tasks, ensuring reliable performance in extreme conditions.
Note: Chrome-plated rod is not induction hardened, and damages due to misuse are not covered under warranty.
Same-Day Shipping: All orders placed before 3 PM will be shipped the same day (excluding weekends and holidays).
Made in Europe: Ensure quality and compliance with international standards.
For assistance in selecting the proper hydraulic cylinder replacement, please contact us at (800) 823-4937.
WCTN2.5×16 Double Acting Hydraulic Cylinder | Northern Hydraulics
SKU: WCTN2.5x16
$251.65 -9% $229.00
1+
$ 229.00/piece
4+
$ 217.55/piece
-5%
8+
$ 206.10/piece
-10%
33 viewed in the last 24 hours
In stock Expected delivery between Oct 13 - Oct 20
No sales tax
Free shipping
