2.5" bore x 28" stroke hydraulic cylinder, 3500 PSI. Welded, strong & reliable. Ideal for heavy-duty applications. Free shipping in the Continental US!
Specifications
| Weight | 38 lbs |
|---|---|
| Dimensions | 40 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 28 |
| Cylinder Extended Length | 64 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 36 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.875 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 37.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 12,700 lbs |
| Cylinder Oil Volume | 2.38 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
- Reliable Performance: The 2.5″ bore x 28″ stroke hydraulic cylinder operates at a powerful 3500 PSI, designed to handle demanding applications with ease.
- Heavy-Duty Construction: Made with a welded style ensuring durability and strength to withstand high loads, rated for a column load of up to 12,700 lbs.
- Optimal Lengths: The overall length is 37.5 inches with an extended length of 64 inches and a retracted length of 36 inches, providing excellent flexibility for various tasks.
- High Oil Volume: Capable of housing 2.38 quarts of oil, this cylinder ensures efficient operation even under heavy demands.
- Chrome Plated Rod: The 1.5 inch diameter chrome plated rod offers resistance to wear and tear, enhancing the longevity of the hydraulic cylinder.
- Cross Tube Rod End: Designed with a cross tube rod end for easy installation and compatibility with various equipment and applications.
- Double Acting Mechanism: This hydraulic cylinder utilizes a double acting action for improved efficiency and performance.
- Versatile Use: Perfect for agricultural machinery, construction equipment, and any application requiring high-performance hydraulics.
Same-Day Shipping: All orders made until 3 pm are shipped the same day (except weekends and holidays).
Free Ground Shipping: Enjoy free ground shipping within the Continental US on your entire order.
Made in Europe: Engineered and constructed using high-quality materials for reliable performance.
If you have any questions or need assistance selecting the right hydraulic cylinder replacement, please do not hesitate to contact us at (800) 823-4937.
2.5 Bore x 28 Stroke Hydraulic Cylinder | Northern Hydraulics
SKU: WCTN2.5x28
$300.00 -7% $279.00
1+
$ 279.00/piece
4+
$ 265.05/piece
-5%
8+
$ 251.10/piece
-10%
33 viewed in the last 24 hours
In stock Expected delivery between Oct 06 - Oct 13
No sales tax
Free shipping
