2.5" bore x 42" stroke hydraulic cylinder rated at 3500 PSI. Heavy-duty, welded design with cross tube, 2-year warranty, free ground shipping in Continental US.
Specifications
| Weight | 52 lbs |
|---|---|
| Dimensions | 54 × 4 × 4 in |
| Cylinder Bore | 2.5" |
| Cylinder Stroke Ranges | 42 |
| Cylinder Extended Length | 92 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 50 |
| Cylinder Port Size | ORB – 8 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.875 in |
| Cylinder Rod Diameter | 1.5 in |
| Cylinder Overall Length | 51.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 6,200 lbs |
| Cylinder Oil Volume | 3.57 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
- Bore Size: 2.5 inches
- Stroke Length: 42 inches
- Overall Length: 51.5 inches
- Extended Length: 92 inches
- Retracted Length: 50 inches
- Maximum Pressure: 3500 PSI
- Column Load Capacity: 6,200 lbs
- Oil Volume: 3.57 quarts
- Rod Diameter: 1.5 inches, chrome plated
- Rod End Type: Cross tube
- Action: Double acting
- Style: Welded
- Ports: SAE 8
This robust 2.5″ bore x 42″ stroke hydraulic cylinder is designed to withstand extreme working conditions. With a maximum pressure rating of 3500 PSI and a column load capacity of 6,200 lbs, it is suitable for a wide range of heavy-duty applications. The chrome-plated rod and welded cross tube design enhance durability and performance.
The hydraulic cylinder features a double-acting mechanism, allowing for efficient operation in both extending and retracting functions. This versatility makes it an excellent choice for construction, agricultural equipment, and industrial machinery.
Key Benefits:
- High strength and durability due to welded construction and high-quality materials.
- Flexible compatibility with various fittings thanks to the SAE 8 ports.
- Easy integration into existing hydraulic systems.
- 2-year warranty for peace of mind.
- Free ground shipping to the continental US.
Usage Instructions: Ensure proper installation following the specifications for your equipment. Regular maintenance checks will enhance the lifespan of the hydraulic cylinder. Always adhere to the manufacturer’s guidelines for hydraulic systems.
Same-Day Shipping: Orders placed before 3 PM will be shipped the same day (excluding weekends and holidays).
Contact Us: If you need assistance choosing the right hydraulic cylinder or have any questions, please reach out at (800) 823-4937.
