Shop the WCTN2x6 hydraulic cylinder with a 2.38″ bore, 6″ stroke, and 3500 PSI. Heavy-duty design, 9,400 lbs column load, and free shipping available!
Specifications
| Weight | 12 lbs |
|---|---|
| Dimensions | 18 × 4 × 4 in |
| Cylinder Bore | 2" |
| Cylinder Stroke Ranges | 6 |
| Cylinder Extended Length | 20 |
| Cylinder Style | Welded |
| Cylinder Retracted Length | 14 |
| Cylinder Port Size | ORB – 6 |
| Manufacturers | Northern Hydraulics |
| Cylinder Outer Diameter | 2.38 in |
| Cylinder Rod Diameter | 1.25 in |
| Cylinder Overall Length | 15.5 in |
| Cylinder PSI | 3500 PSI |
| Cylinder Column Load | 9,400 lbs |
| Cylinder Oil Volume | 0.33 qts |
| Cylinder Rod Type | Chrome Plated |
| Cylinder Rod End | Cross Tube |
| Cylinder Action | Double Acting |
Overview
Introducing the WCTN2x6 Hydraulic Cylinder, designed to deliver powerful performance for your heavy-duty needs. With a rugged and durable construction, this welded hydraulic cylinder is perfect for a range of applications that require reliable and efficient hydraulic operation.
- Bore Diameter: 2.38 inches
- Stroke Length: 6 inches
- Extended Length: 20 inches
- Retracted Length: 14 inches
- Operating Pressure: 3500 PSI
- Column Load Capacity: 9,400 lbs
- Oil Volume: 0.33 quarts
- Rod Diameter: 1.25 inches
- Rod Type: Chrome Plated
- Action: Double Acting
- Rod End Type: Cross Tube
- Ports: SAE 6
This hydraulic cylinder’s versatility makes it an ideal replacement for various equipment, ensuring that even the most demanding tasks are handled with ease. Built for heavy-duty applications, the WCTN2x6 hydraulic cylinder is suitable for use in industries such as construction, agriculture, and manufacturing.
Key Features:
- Welded design for enhanced durability and leak resistance.
- Compatible with a range of mounting options for easy installation.
- Efficient double acting mechanism for rapid operation.
Note: Please ensure proper installation and usage to avoid potential issues. Misuse or incorrect application does not fall under warranty coverage.
Enjoy Free Ground Shipping on your order within the continental US! All orders placed by 3 pm are eligible for same-day shipping (excluding weekends and holidays).
If you’re looking for assistance in choosing the right hydraulic cylinder for your needs or have any questions, feel free to reach out to us at (800) 823-4937.
